Microprocessor based temperature controller with membrane keypad and eye level control panel.
Controls the internal temperature within ± 0.5
Temperature range adjustable from 0°C to -25.0°C
PLC 4.3 ‘’ Display touch screen with USB port for data -optional
High quality PT-100 Sensor for better accuracy
The cabinet insulated with high density CFC free Poly Urethane Foam-PUF.
Interior of chamber is stainless steel (304, 1.0 mm thick).
The exterior is white powder coated (1.0 mm thick) mild steel
Door has a magnetic silicon gasket with lock.
Stainless steel tray is provided inside the chamber
The cooling is affected by CFC free refrigeration system
LED Display show of set value and process value
Audio- Visual Alarm, Door Open/Closed, Temperature High/Low, Power Failure, Compressor ON Indication, Power ON Indication, Battery Low, Sensor Failure -Optional
ISO 9001 standard and CE certified.
Lockable Castor wheels for ease of mobility
Double gasket seal, dual door system door tight sealing to prevent temperature
Specially designed Stainless-steel trays can be pulled out for easy handling
Less than 65 dBA and low vibration compressor.
Circuit breaker MCB, Heavy duty latch with lock & key.
Compressor fan air filter for cleaning and maintenance.
7 days circular chart recorder for temperature recorder-Optional
Door Heating System through compressor discharge line .
Battery backup for dedicated alarm-Optional
Frost free refrigeration system
High quality door opening handle for smooth operation with safety lock.
