Front Panels toughened transparent scratch resistance glass of 6mm thickness.
Motorized front glass door Shattered
10° slanted view screen provides highly visible and easily accessible area Sturdy constriction of cabinet protects from air leakage from the working zone
A programmable logic controller (PLC) is used for controlling
Large front panel color 4.3’ Touch display and user friendly
Display show Life of UV lamp, HEPA filter and pressure
Wheel with leveling jack for vibration free operation
2 supply valves are available for extensive function, compatible with liquid, gas and vacuum
2 water proof power outlet socket are located in the side panel
UV interlock system and Manometer to measure the air pressure-optional
Front sash door height can be easily adjustable
The closing/opening of front door is integrated with the UV ON/OFF
Double inlet blower motor 275 watt/230vac 50 Hz with 1440 rpm fitted to reduces vibration less than 2.5 um. and noise level lower than 65 db
Audio and visual alarms for HEPA filter failure
Pre-filters Filtration efficiency of 98% for particles of sizes 10 micron
HEPA efficiency 99.997% for all types of particles of sizes 0.3 micron with leak proof gaskets
Fluorescent tube lights with diffuser SS for lux on work surface
