SALIENT FEATURES

• Micro controller-based digital controller with timer and password protection
• Digital Temperature Controller set at 121.1°c and 15 PSI with 0.1°c Accuracy/ Resolution
• Digital timer range 0 to 99 min.
• Autoclave chamber double body construction.
• Single Chamber for Steam and Water with covered externally by outer shell.
• Inner chamber made of heavy gauge (16 swg.) stainless Steel 304 grade .
• Outer body made of S.S. 304 grade mirror finished.
• The space between outer wall and inner is filled with high grade glass wool.
• Tank Pressure tested up to 22 PSI factory
• Lid made of thick stainless steel fitted with Pressure Gauge, two Safety Valves.
• Vacuum Breaker to remove air pockets.
• Manual Steam Release Valve and 3/8” BSP Port fitted with coupling for Validation purpose
• Autoclaving time cycle starts automatically when set temperature and pressure is achieved.
• Solenoid valve for Purging and automatic release of Steam once autoclaving cycle gets completed.
• Alram indication cycle end, sensor failure, water level low
• Automatic Pressure Control Switch as an additional safety device
• Low water level cut-off which automatically cuts off power to heater
• Online documenting of 1 temperature and 1 pressure channel along with F0 summation -Optional
• Touch screen PLC -Optional
• Ergonomically designed closing of lid
• Paddle Door lifting Mechanism
• Over temperature safety with independent alarm
• Chamber designed and hydraulically tested as per guidelines
• Chamber and lid fully SS 304. External panels also of SS 304
• Stainless-steel 304 grade rod type basket
• Silicon gasket fitted with chamber
• Certification ISO 9001:2015, ISO13485:2016 ISO 14001:2015
• MCB for electrical safety, drain cock, Safety Pressure Valve
